MEM09005: Fundamentals of Engineering Drafting

Description

This unit of competency defines the skills and knowledge required to produce drawings to AS 1100 Technical drawing or equivalent using manual drafting or drawing equipment, where the critical dimensions, associated tolerances and design specifications are predetermined.
Where a computer-aided design (CAD) system is used unit MEM09009 Create 2-D drawings using computer-aided design system and MEM09010 Create 3-D models using computer-aided design system, should be selected as appropriate.
